Aluminium Alloy Castings


Image 01 Image 02 Image 03 Image 04 Image 05 Image 06

We are a Manufacturer and Supplier of Aluminium Alloy Sand Casting & Aluminium Alloy Die Casting. Aluminium Alloy Castings are manufactured using high grade raw material, and are in tune with the highest industrial standards. Aluminium Alloy Castings are manufactured in accordance with industrial standards as per the requirement of the clients. Our Aluminium Alloy Castings are manufactured using skilled manpower. Also, these Aluminium Alloy Castings are supplied with Test certificates for chemical composition and physical properties. We make critical automotive components like cylinder heads, pistons, manifolds, wheel hubs, brake assemblies, water pump casings, alternator casings etc.

Highlights
  • High performance
  • Ductile strength
  • Sturdy construction
  • Quality standards
  • Light Weight


Chemical Composition

Alloy Designation Copper Silicon Magnesium Iron Manganese Nickel Zinc Lead Tin Titanium
LM-2 0.7-2.5 9.0-11.5 0.3 1.0 0.5 0.5 2.0 0.3 0.2 0.2
LM-4 2.0-4.0 4.0-6.0 0.15 0.8 0.2-0.6 0.3 0.5 0.1 0.1 0.2
LM-6 0.1 10.0-13.0 0.10 0.6 0.5 0.1 0.1 0.1 0.05 0.2
LM-13 0.7-1.5 10.0-12.0 0.8-1.0 1.0 0.5 0.7-1.5 0.5 0.1 0.1 0.2
LM-14 3.5-4.5 0.7 1.2-1.8 0.7 0.6 1.7-2.3 0.1 0.05 0.05 0.2
LM-24 3.0-4.0 7.5-9.5 0.3 1.3 0.5 0.5 3.0 0.3 0.2 0.2
ADC-12 1.5-3.5 9.6-12.0 0.3 0.9 0.5 0.5 1.0 - 0.3 -
ALSI-132 1.75-2.5 11.0-12.5 0.03 0.7-1.0 0.5 0.3 1.4 0.01 - -
